BP-W105 WC Flusher for Commode Bharat Photon

BP-W105 WC Flusher for Commode Bharat Photon

Out of stock

Rs. 7,190.00
Rs. 7,990.00 Rs. 7,190.00
10% OFF Sold out
Shipping calculated at checkout.
Power

Hands-free hygiene for modern restrooms. AC-powered sensor flusher with concealed mounting. Reduces water waste and cross-contamination. Durable, reliable, and easy to install.

Features

  • Touch-free infrared sensor for hygienic operation
  • Hands-free flushing for improved cleanliness
  • 1-minute automatic safety shut-off
  • Durable chrome-plated ABS body
  • Water-saving efficient flushing system
  • Ideal for medium to high usage areas
  • Suitable for commercial & residential use

Specifications

  • Power: 220V AC
  • Application: No-touch infrared wc flusher
  • Sensing Range: Adjustable (50-650mm)
  • Water Pressure: 0.01Mpa-0.8Mpa 40mm Inlet/Outlet orifice Top to Bottom
  • Flush Time: 10 sec post-flush
  • Connection: G1/2” (DN15) inlet/outlet
  • USP: Inbuilt brass flow control, easily serviceable
  • Material: SS screw-less front, ABS frame & box, PoM solenoid with brass flow control
  • Warranty: 2 years (manufacturing defects only)

Usage Information

The BP-W105 Automatic WC Flusher is designed for modern washrooms requiring touch-free hygiene and controlled water usage. Ideal for offices, malls, hotels, hospitals, airports, educational institutions, and premium residential projects.
Power Options Explained:

  • AC (Electric Operated): Ideal for high-traffic locations with continuous power supply.

Warranty & Support

  • 2 Years Manufacturer Warranty (manufacturing defects only)
  • Covers sensor unit, push button & internal components
  • Excludes physical damage, improper installation & water quality issues
  • Pan India service support available
  • Genuine spare parts available on request

Installation

  • Concealed wall-mounted installation
  • Requires standard G1/2” water inlet connection
  • Operates on AC power supply (ensure proper wiring)
  • Professional plumber/electrician installation recommended
  • Ensure correct water pressure for optimal flushing performance
View full details

Frequently Asked Questions

What warranty is provided?

The product comes with a manufacturer warranty covering manufacturing defects. Warranty terms may vary by model.

Is the urinal sensor suitable for commercial washrooms?

Yes, it is ideal for commercial spaces such as malls, offices, airports, hotels, hospitals, and public restrooms due to its hygienic, touch-free operation.

Can the urinal sensor be installed in existing urinals?

Yes, the urinal sensor is designed for easy retrofit installation and can be installed in most standard urinals without major plumbing changes.

Does using a urinal sensor help save water?

Absolutely. The sensor flushes only when required, reducing unnecessary water usage and helping maintain an eco-friendly and cost-efficient washroom.

Is the urinal sensor compatible with both AC and DC power?

Yes, the urinal sensor is available in DC type as well as AC/DC type, offering flexible power options based on installation requirements.

How does a urinal sensor work?

A urinal sensor uses infrared (IR) technology to detect user presence. When a person steps away after use, the sensor automatically activates the flush without any physical contact.
